Programmer’s Guide 11-7
SCPI Command Summary
SCPI Device Command Summary
Table 11-2 CALCulate (3 of 7)
1. Binary parameters accept the values of 1 (on) and 0 (off) in addition to ON and OFF.
2. Numeric parameters may include an appropriate suffix; if no suffix is included, the
default (HZ for frequency or S for time) is assumed.
SUBSYSTEM COMMANDS FORM DESCRIPTION
CALCulate[1|2]:LIMit:MARKer
:STATistic:PEAK:STATe
<ON|OFF>
1
NR1 Turns statistic peak-to-peak marker
limit test on/off.
CALCulate[1|2]:LIMit:MARKer
:TILT:MAXimum <num>
2
NR3 Sets the maximum value for delta
amplitude marker limit test.
CALCulate[1|2]:LIMit:MARKer
:TILT:MINimum <num>
2
NR3 Sets the minimum value for delta
amplitude marker limit test.
CALCulate[1|2]:LIMit:MARKer
:TILT [:STATe] <ON|OFF>
1
NR1 Turns delta amplitude marker limit
testing on or off.
CALCulate[1|2]:LIMit:SEGMent
[1|2|12]:AMPLitude:STARt
<num>
2
NR3 Sets the Begin Limit for the specified
limit segment.
CALCulate[1|2]:LIMit:SEGMent
[1|2|12]:AMPLitude:STOP
<num>
2
NR3 Sets the End Limit for the specified
limit segment.
CALCulate[1|2]:LIMit:SEGMent
:AOFF
command
only
Turns off all limit segments for a
given channel — deletes all segments
in the channel's limit table.
CALCulate[1|2]:LIMit:SEGMent
[1|2|12]:DISTance:STARt
<num>
2
NR3 Sets the Begin Distance for the
specified limit segment.
(Option 100 only)
CALCulate[1|2]:LIMit:SEGMent
[1|2|12]:DISTance:STOP <num>
2
NR3 Sets the End Distance for the
specified limit segment.
(Option 100 only)
CALCulate[1|2]:LIMit:SEGMent
[1|2|12]:FREQuency:STARt
<num>
2
NR3 Sets the Begin Frequency for the
specified limit segment.
