Agilent Technologies 8712ET Programmer's Guide

11-20 Programmer’s Guide
SCPI Command Summary
SCPI Device Command Summary
Table 11-9 DISPlay (1 of 7)
1. Binary parameters accept the values of 1 (on) and 0 (off) in addition to ON and OFF.
2. Refer to "Displaying Measurement Results" in Chapter 7 of the User's Guide for
more information on using this command.
SUBSYSTEM COMMANDS FORM DESCRIPTION
DISPlay:ANNotation:CHANnel[1|
2][:STATe] <OFF|ON>
1
NR1 Enables/disables measurement
channel annotation.
DISPlay:ANNotation
:CHANnel[1|2]:USER:LABel:DATA
<string>
2
STRING Specifies the string to be displayed in
the measurement channel annotation
area (above the graticule).
DISPlay:ANNotation
:CHANnel[1|2]:USER:STATe<OFF|
ON>
1,2
NR1 Enables user-defined measurement
channel annotation.
DISPlay:ANNotation:CLOCk
:DATE:FORMat <char>
CHAR Selects the Year/Month/Day ordering
of the date in the clock display —
choose from YMD|MDY|DMY.
DISPlay:ANNotation:CLOCk
:DATE:MODE <char>
CHAR Selects the format for the date in the
clock display — choose NUMeric or
ALPHa.
DISPlay:ANNotation:CLOCk
:MODE <char>
CHAR Selects how the clock will appear in the
measurement display title area —
choose from LINE1|LINE2|OFF.
DISPlay:ANNotation:CLOCk
:SEConds[:STATe]<ON|OFF>
1
NR1 Turns on/off display of seconds in the
clock display.
DISPlay:ANNotation
:FREQuency[1|2]:MODE <char>
CHAR Sets the frequency annotation on the
display — choose SSTOP (start/stop),
CSPAN (center/span) or CW.
DISPlay:ANNotation
:FREQuency[1|2]:RESolution
<char>
CHAR Sets the resolution of display
frequency values — choose from
MHZ|KHZ|HZ.
DISPlay:ANNotation:FREQuency
[1|2] [:STATe] <OFF|ON>
1
NR1 Enables/disables frequency
annotation.
DISPlay:ANNotation:FREQuency
[1|2]:USER:LABel:DATA<string>
STRING A user-defined X-axis label.
