Programmer’s Guide 11-21
SCPI Command Summary
SCPI Device Command Summary
Table 11-9 DISPlay (2 of 7)
1. Binary parameters accept the values of 1 (on) and 0 (off) in addition to ON and OFF.
2. Refer to “Displaying Measurement Results” in Chapter 7 of the User’s Guide for
more information on using this command.
SUBSYSTEM COMMANDS FORM DESCRIPTION
DISPlay:ANNotation:FREQuency
[1|2]:USER:STARt<num>
2
NR3 Specifies the start value for
user-defined frequency annotation.
DISPlay:ANNotation:FREQuency
[1|2]:USER:STATe[OFF|ON]
1,2
NR1 Enables user-defined frequency
annotation.
DISPlay:ANNotation:FREQuency
[1|2]:USER:STOP<num>
2
NR3 Specifies the stop value for
user-defined frequency annotation.
DISPlay:ANNotation:FREQuency
[1|2]:USER:SUFFix[:DATA]
<string>
2
STRING Specifies the suffix for user defined
frequency annotation.
DISPlay:ANNotation:LIMit:ICON
[1|2]:FLAG[:STATe] <ON|OFF>
1
NR1 Enables/disables the display of the
limit test fail icon.
DISPlay:ANNotation:LIMit:ICON
[1|2] :POSition:X <num>
NR1 Positions the limit test pass/fail text
and icon on the display. Accepts
whole number values from 0 (flush
left) to 100 (flush right).
DISPlay:ANNotation:LIMit:ICON
[1|2] :POSition:Y <num>
NR1 Positions the limit test pass/fail text
and icon on the display. Accepts
whole number values from 0 (bottom
of display) to 100 (top of display).
DISPlay:ANNotation:LIMit:ICON
[1|2] :TEXT[:STATe] <ON|OFF>
1
NR1 Turns the limit test "PASS/FAIL"
text on or off.
DISPlay:ANNotation:MARKer[1|2]
:NUMBers [:STATe] <OFF|ON>
1
NR1 Enables/disables the display of
marker numbers on trace markers.
DISPlay:ANNotation:MARKer[1|2]
[:STATe]<ON|OFF>
1
NR1 Enables/disables the active marker
annotation for measurement
channels 1 and 2.
