Agilent Technologies 8712ET Programmer's Guide

11-22 Programmer’s Guide
SCPI Command Summary
SCPI Device Command Summary
Table 11-9 DISPlay (3 of 7)
1. Refer to "Operator Interaction" in Chapter 7 of the User's Guide for more informa-
tion on using this command.
2. Binary parameters accept the values of 1 (on) and 0 (off) in addition to ON and OFF.
SUBSYSTEM COMMANDS FORM DESCRIPTION
DISPlay:ANNotation:MESSage:AOFF command
only
Turns off any currently showing
message window — includes
message window, active entry
and IBASIC window.
DISPlay:ANNotation:MESSage
:CLEar
1
command
only
Removes a user-defined pop-up
message window.
DISPlay:ANNotation:MESSage
:DATA <string>
1
STRING Displays a user-defined message
in the pop-up message window.
Optional argument specifies the
timeout: choose from
NONE|SHORt|MEDium|LONG.
DISPlay:ANNotation:MESSage
:STATe <ON|OFF>
1
NR1 Enables/disables the message
window — CAUTION: this
suppresses display of all
messages (even ERROR
messages).
DISPlay:ANNotation:TITLe[1|2]
:DATA <string>
1
STRING Enters a string for the specified
title line.
DISPlay:ANNotation:TITLe[:STATe]
<ON|OFF>
1
NR1 Turns on/off display of the title
and clock.
DISPlay:ANNotation:YAXis:MODE
<char>
CHAR Sets mode for the Y-axis labels —
choose RELative or ABSolute
DISPlay:ANNotation:YAXis[:STATe]
<ON|OFF>
2
NR1 Turns on/off Y-axis labels.
DISPlay:CMAP:COLor[1|2|…16]
:GREYscale <num>
NR2 Changes the default intensity of
the selected item on the
analyzer's internal monitor.
