Programmer’s Guide 11-33
SCPI Command Summary
SCPI Device Command Summary
Table 11-14 MMEMory (3 of 3)
1. Binary parameters accept the values of 1 (on) and 0 (off) in addition to ON and OFF.
2. File names may include the mass storage device name—MEM:( internal non-volatile
memory), RAM: (internal volatile memory), INT: (internal 3.5” disk drive), or NFS
local path. Wildcards ? and * may be used.
3. Refer to “Automated Measurement and Control” in Chapter 7 of the User’s Guide for
more information on using this command
4. Refer to the Example Programs Guide for more information on using this command.
5. Refer to the example programs PUTFILE and GETFILE in the Example Programs
Guide.
SUBSYSTEM COMMANDS FORM DESCRIPTION
MMEMory:STORe:STATe:TSCAL
<ON|OFF>
1
NR1 When on, the saved state will be
the test set cal only.
MMEMory:STORe:TRACe
<char>,<string>
2, 3
command
only
Stores an ASCII list of trace and
frequency values to a file — char
is the formatted data trace
CH<1|2>FDATA and string is
the filename.
MMEMory:STORe:TRACe:FORMat
<char>
CHAR Selects the format that the ASCII
data will be saved in. Choose
from LOTus 123 or TOUChstone.
MMEMory:TRANsfer:BDAT
<string>
2
[,<block>]
4
STRING,
BLOCK
Copies a file to or from the
analyzer's disk drive.
5
MMEMory:TRANsfer[:HFS]
<string>
2
[,<block>]
4
STRING, Copies a file to or from the
analyzer's disk drive.
5
