Programmer’s Guide 11-45
SCPI Command Summary
SCPI Device Command Summary
Table 11-19 SENSe (8 of 16)
1. Binary parameters accept the values of 1 (on) and 0 (off) in addition to ON and OFF.
2. Numeric parameters may include an appropriate suffix; if no suffix is included, the
default (HZ for frequency or S for time) is used.
3. For use with structural return loss measurements using analyzers with Option 100
only.
SUBSYSTEM COMMANDS FORM DESCRIPTION
SENSe[1|2]:CORRection:EXTension[:
STATe]<ON|OFF>
1
NR1 Enables port extensions.
SENSe[1|2]:CORRection:EXTension
:TRANsmission[:TIME] <num>
2
NR3 Specifies the port extension at
the transmission port, in
seconds.
SENSe[1|2]:CORRection:IMPedance
:INPut:MAGNitude<num>
2
NR3 Specifies the reference
impedance for the Smith chart
display. The default is the
analyzer's system impedance.
SENSe[1|2]:CORRection:IMPedance
:INPut:MAGNitude:SELect ZO_50
NR1 Selects 50 ohms as the system
impedance.
SENSe[1|2]:CORRection:IMPedance
:INPut:MAGNitude:SELect ZO_75
NR1 Selects 75 ohms as the system
impedance.
SENSe[1|2]:CORRection:ISOLation
[:STATe] {OFF|0|ON|1}
NR1 Enables or disables use of
isolation error correction when
2-port calibrations are selected.
SENSe[1|2]:CORRection:LENGth
:COAX <num>
2
NR2 Specifies the length of cable to
be calibrated, in feet or
meters.
3
SENSe[1|2]:CORRection:LENGth
:CONNector <num>
2
NR2 Specifies the length of an
interface connector, in mm or
inches.
3
SENSe[1|2]:CORRection:LOSS
:COAX <num>
2
NR2 Specifies the loss of a cable
under test, in dB/100 ft.
3
