Programmer’s Guide 11-47
SCPI Command Summary
SCPI Device Command Summary
Table 11-19 SENSe (10 of 16)
1. For use with fault location measurements on analyzers with Option 100 only.
2. Numeric parameters may include an appropriate suffix; if no suffix is included, the
default (HZ for frequency or S for time) is assumed.
SUBSYSTEM COMMANDS FORM DESCRIPTION
SENSe[1|2]:CORRection:TESTSET command
only
Brings up the Test Set Cal menu.
2
SENSe[1|2]:CORRection:THReshol
d:COAX <num>
NR2 Selects multi-peak threshold value,
in dB.
1
SENSe[1|2]:COUPle <char> CHAR Turns the alternate sweep mode
on/off — choose ALL (coupled sweep)
or NONE (alternate sweep).
SENSe[1|2]:DETector[:FUNCtion]
<char>
CHAR Specifies which detection mode is
used to make the measurement —
choose BBANd (broadband) or NBANd
(narrowband).
SENSe[1|2]:DISTance:CENTer
<num>
NR3 Sets the center distance for a fault
location measurement, in
feet or meters.
1
SENSe[1|2]:DISTance:STARt
<num>
NR3 Sets the start distance for a fault
location measurement, in feet or
meters.
1
SENSe[1|2]:DISTance:UNITs
<char>
CHAR Specifies distance units. Choose
METers or FEET.
1
SENSe[1|2]:DISTance:STOP <num> NR3 Sets the stop distance for a fault
location measurement, in feet or
meters.
1
SENSe[1|2]:FREQuency:CENTer
<num>
2
NR3 Sets the center frequency of the RF
source.
