Reading Analyzer Data
Array-Data Formats
Table 4-2 Network Analyzer Array-Data Formats
Format
Type
Type of Data Bytes per
Data Value
Bytes per point
2 data values
(201 pts)
Bytes per trace
Total Bytes
with header
FORM 1 Internal
Binary
N/A 6 1206 1210
FORM 2 IEEE 32-bit
Floating-Point
4 8 1608 1612
FORM 3 IEEE 64-bit
Floating-Point
8 16 3216 3220
FORM 4 ASCII Numbers 24
(Typical)
50
(Typical)
10,050
(Typical)
10,050
1
(Typical)
1. FORM4 does not use a header.
FORM 5 PC-DOS 32-bit
Floating-Point
4 8 1608 1612
