Agilent Technologies 8720E Series Programmer's Guide

Chapter 1 1-35
Alphabetical Command Reference
CLASS
CLASS
Syntax
CLASS<11A|11B|11C|22A|22B|22C>;
Description
These commands call reflection standard classes during a calibration sequence. If only one
standard is in the class, it is measured. If there is more than one, the standard being used
must be selected with STAN<A|B|C|D|E|F|G>. If there is only one standard in the class,
these commands are OPC-compatible.
EXAMPLE To measure the female open of a type-N cal kit:
OUTPUT 716;"CLASS11A;OPC?;STANB;"
ENTER OPC;
Front Panel Equivalents
Command Description Range Query Response
CLASS11A S11A: S11 (forward reflection) 1-port, open N/A N/A
CLASS11B S11B: S11 (forward reflection) 1-port, short N/A N/A
CLASS11C S11C: S11 (forward reflection) 1-port, load N/A N/A
CLASS22A
1
1. ES models only.
S22A: S22 (reverse reflection) 1-port, open N/A N/A
CLASS22B
1
S22B: S22 (reverse reflection) 1-port, short N/A N/A
CLASS22C
1
S22C: S22 (reverse reflection) 1-port, load N/A N/A
Command Hardkey Softkey
CLASS11A
CLASS11B
CLASS11C
CLASS22A
CLASS22B
CLASS22C
Cal
S11A
Cal
S11B
Cal
S11C
Cal
S22A
Cal
S22A
Cal
S22A
