Agilent Technologies 8720E Series - Page 505

A-4 AppendixA
Preset Conditions
Preset State
Table A-2 Stimulus Conditions
Preset Conditions Preset Value
Sweep Type Linear Frequency
Step Sweep (8720E series only)
Off
1
Step Sweep (8719/20/22ES Opt. 085 only) On
Display Mode Start/Stop
Trigger Type Continuous
External Trigger Off
Sweep Time 100 ms, Auto Mode
Start Frequency:
8720E series 50 MHz
8753ES 30 kHz
8753ES Option 011 300 kHz
8753ES Option 011 w/ Option 006 30 kHz
8753ET 300 kHz
Stop Frequency:
8719ET/ES 13.51 GHz
8720ET/ES 20.05 GHz
8722ET/ES 40.05 GHz
8753ET/ES 3.0 GHz
8753ET/ES Option 006 6.0 GHz
Frequency Span (Stop Frequency − Start Frequency)
Start Time 0
Time Span 100 ms
CW Frequency 1000 MHz
Source Power Setting:
8719ET/ES and 8720ET/ES 0 dBm
8719ET/ES and 8720ET/ES Option 007 10 dBm
8719ET/ES and 8720ET/ES Option 400 0 dBm
8722ET/ES −10 dBm
8722ET/ES Option 007 −5 dBm
8753ET/ES 0 dBm
Source Power On/Off On
