Chapter 15 415
W-CDMA Digital Modulation for Component Test
W-CDMA Downlink Modulation
NOTE For additional information on TFCI, TPC, and pilot power offsets, refer to “Understanding
TFCI, TPC, and Pilot Power Offsets” on page 432.
10. Highlight the value (4) in the Pilot Bits field.
11. Press
Edit Item > 8.
12. Highlight the value (RANDOM) in the Data field.
13. Press
Edit Item > PN9.
14. Highlight the value (STD) in the Scramble Type field.
15. Press
Edit Item > Right Alternate.
16. Highlight the value (0) in the Scramble Offset field.
17. Press
Edit Item > 1 > Enter.
NOTE For additional information on Scramble Type and Scramble Offset, refer to “Calculating
Downlink Scramble Codes” on page 434.
The downlink DPCH channel parameters have now been modified, as shown. Other channel parameters can
be modified in the same manner.
Figure 15-2
