Chapter 16 541
W-CDMA Uplink Digital Modulation for Receiver Test
Setting Up Compressed Mode for a Multiple TGPS Transmission
Figure 16-63 Multiple TGPSIs on the Spectrum Analyzer Display
TGPSI 2—5 Frames
PwrOffs—6 dB
TGPSI 1—5 Frames
TGPSI 1
TGL1—5 Slots
TGPSI 1
TGL2—7 Slots
TGPSI 2
TGL1—7 Slots
TGPSI 2
TGL2—3 Slots
TGPSI 1
TGCFN 0
TGPSI 2
TGCFN 1
