72 Chapter 2
Status Registers
Use Status Registers to Determine the State of Analyzer Events and Conditions
The STATus:OPERation condition register contains the following bits:
Bit Decimal
Value
Description
00Calibrating: A 1 in this bit position indicates that the
analyzer is performing a self-calibration.
12Reserved: This bit is not used by the analyzer, but is for
future use with other Agilent products.
24Reserved: This bit is not used by the analyzer, but is for
future use with other Agilent products.
38Sweeping: A 1 in this bit position indicates that a sweep is
in progress.
4
a
a. The description of this bit refers to any measurement under the MEASURE key.
16 Measuring: A 1 in this bit position indicates that a
measurement is in progress.
5
a
32 Waiting for Trigger: A 1 in this bit position indicates
that a measurement is in a “wait for trigger” state.
664Reserved: This bit is not used by the analyzer, but is for
future use with other Agilent products.
7 128 Reserved: This bit is not used by the analyzer, but is for
future use with other Agilent products.
8 256 Paused: A 1 in this bit position indicates that the instrument
is in the paused state of the measurement.
9 512 Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
10 1024 Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
11 2048 Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
12 4096 Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
13 8192 Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
14 16384 Reserved: This bit is not used by the analyzer, but are for
future use with other Agilent products.
15 32768 Always Zero (0)
