Replaceable Parts
Cables
3-22
Inside Front Panel View
Table 3-8 Inside Front Panel View
Reference
Designator
Description Qty Part Number
A4W1
*
*. This cable is not replaceable by itself. You must order the corresponding assembly.
Wire Cable, A4 Inverter to P12 of A31 Motherboard 1 (part of A4)
A2DS1W1
* Wire Cable, A2DS1 to A4 Inverter 1 (part of A2)
A1W1
* Ribbon Cable, A1 Keyboard to P13 of A31 Motherboard 1 (part of A1)
W1 Flexible Cable, EXT 1 to J401 of A11 Pulse/Analog Modulation Generator 1 8121-0628
W2 Flexible Cable, EXT 2 to J402 of A11 Pulse/Analog Modulation Generator 1 8121-0628
W3 Flexible Cable, LF OUTPUT to J403 of A11 Pulse/Analog Modulation Generator 1 8121-0628
W4 Flexible Cable, ALC INPUT to J4 of A10 ALC 1 8121-0609
W5 Flexible Cable, PULSE/TRIGGER GATE INPUT to J201 of A11 Pulse/Analog Modulation Generator 1 8121-0625
W6 Flexible Cable, PULSE VIDEO OUT to J203 of A11 Pulse/Analog Modulation Generator 1 8121-0625
W7 Flexible Cable, PULSE SYNC OUT to J202 of A11 Pulse/Analog Modulation Generator 1 8121-0625
W8 Ribbon Cable, A3 Power Switch (DATA CABLE) to A2 Display 1 8121-0165
W9 Ribbon Cable, P1 of A3 Power Switch to P11 of A31 Motherboard 1 8121-0614
