Replaceable Parts
Cables
3-24
Main Chassis Top View
Table 3-9 Main Chassis Top View
Reference
Designator
Description Qty Part Number
W1 Flexible Cable, EXT 1 to J401 of A11 Pulse/Analog Modulation Generator 1 8121-0628
W2 Flexible Cable, EXT 2 to J402 of A11 Pulse/Analog Modulation Generator 1 8121-0628
W3 Flexible Cable, LF OUTPUT to J403 of A11 Pulse/Analog Modulation Generator 1 8121-0628
W4 Flexible Cable, ALC INPUT to J4 of A10 ALC 1 8121-0609
W5 Flexible Cable, PULSE/TRIGGER GATE INPUT to J201 of A11 Pulse/Analog Modulation Generator 1 8121-0625
W6 Flexible Cable, PULSE VIDEO OUT to J203 of A11 Pulse/Analog Modulation Generator 1 8121-0625
W7 Flexible Cable, PULSE SYNC OUT to J202 of A11 Pulse/Analog Modulation Generator 1 8121-0625
W10 Flexible Cable, J3 of A9 YIG Driver to J1031 of A31 Motherboard 1 8121-0621
W11 Flexible Cable, J4 of A9 YIG Driver to J1021 of A31 Motherboard 1 8121-0625
W12 Ribbon Cable, J5 of A9 YIG Driver to J1 of A28 YIG Oscillator 1 8121-0608
W13 Flexible Cable, J201 of A10 ALC to J6 of A30 Modulator Filter with Standard or High Power 1 8121-0624
W14 Flexible Cable, J5 of A10 ALC to A23 Low Band Coupler/Detector 1 8121-0627
W15 Flexible Cable, J3 of A10 ALC to A25 High Band Detector 1 8121-0607
W16 Flexible Cable, J204 of A11 Pulse/Analog Modulation Generator to A20 SMI 1 8121-0625
W17 Flexible Cable, J205 of A11 Pulse/Analog Modulation Generator to J7 of A30 Modulator Filter with
Standard or High Power
1 8121-0626
W18 Ribbon Cable, J1 of A18 CPU to J3 of A21 Rear Panel 1 8121-0617
W19 Ribbon Cable, J2 of A18 CPU to J30 of A26 MID [Microcircuit Interface Deck] 1 8121-0619
