Troubleshooting
Troubleshooting Adjustment Problems
1-53
Troubleshooting Adjustment Problems
When an adjustment does not work or fails to resolve a problem and all self-tests have passed, use the
following table to locate the most likely failure.
Table 1-34 Troubleshooting Help for Failed Adjustments
Adjustment that is failing... Assemblies most likely causing failure...
ADC Calibration A18 CPU
YIG-Driver Pre-Tune Calibration A9 YIG Driver
A28 YIG Oscillator
A5 Sampler
A6 Frac-N
VCO Bias Franc-N Calibration A6 Frac-N
Internal Source Calibration A11 Pulse/Analog Modulation Generator
AM Audio Path Offset Calibration A11 Pulse/Analog Modulation Generator
KV vs. Frequency Calibration A6 Frac-N
Timebase Calibration A7 Reference
FM Scale Offset Calibration A11 Pulse/Analog Modulation Generator
FM Path Offset Calibration A11 Pulse/Analog Modulation Generator
A6 Frac-N
FM In-band Offset Calibration A6 Frac-N
FM Inverting Amplifier Offset Calibration A6 Frac-N
FM 1/2 Path Ratio Gain Calibration A11 Pulse/Analog Modulation Generator
Mod Source Relative Gain Calibration A11 Pulse/Analog Modulation Generator
FM/PM Out-of- Band Calibration A6 Frac-N
FM/PM YO Frequency Compensation Calibration A9 YIG Driver
A28 YIG Oscillator
DC FM Calibration A6 Frac-N
A11 Pulse/Analog Modulation Generator
Low Frequency Output Calibration A11 Pulse/Analog Modulation Generator
External Input Peak Detector Calibration A11 Pulse/Analog Modulation Generator
ALC Dynamic Calibration A10 ALC
A30 Modulation Filter
A8 Output
Power Flatness Calibration A10 ALC
RF Path
Attenuator Calibration-Low Band and High Band Power AT1
RF Path
Attenuator Calibration-High Band and High Power AT1
RF Path
Attenuator Calibration-Low Band and Low Power AT1
RF Path
