Replaceable Parts
Hardware and Other Instrument Parts
3-42
Disassembled A32 10 MHz Crystal Oscillator (Option UNJ)
Figure 3-18 Disassembled A32 10 MHz Crystal Oscillator (Option UNJ)
Table 3-18 Disassembled A32 10 MHz Crystal Oscillator (Option UNJ)
Item No. Description Qty Part Number
1 C-Bracket 1 E8251-00040
2 Shock Mount 3 1520-0205
3 Flathead Washer 3 3050-0105
4 Screw-Machine 4.0 x 40 .250 3 2200-0103
5 L-Bracket 1 E8251-00041
6 Screw-Machine M3.0 x 8 CW-PN-TX 2 0515-0372
7 Nut-Hex M3.0 (line module ground) 1 0535-0031
8 Screw-Machine M3.0 x 8 CW-PN-TX 3 0515-0372
