Replaceable Parts
Hardware and Other Instrument Parts
3-38
Disassembled Front Panel View
Table 3-16 Disassembled Front Panel View
Item No. Description Qty Part Number
1 Front Panel Frame 1 E8251-20102
2 Gasket RFI Round Mesh .125 inch 1 8160-0660
3 Gasket RFI Round Mesh .062 inch 1 8160-0723
4 Velcro Attachment 1 0510-1303
5 Glass Filter 70% Xmt 1 4330-1711
6 Rubber Keypad CW (E8241A and E8244A Models Only) 1 E8251-40009
Rubber Keypad Analog (E8251A and E8254A Models Only) 1 E8251-40006
7 Bracket Filter 1 E4400-00009
8 Screw-Machine M3.0 x 08 FL-TX 14 0515-1227
9 Cable Retainer Clip 3 1400-2293
10 Sub Panel 1 E8251-00009
11 Screw-Machine M3.0 x 06 CW-PN-TX 17 0515-0372
12 Screw-Machine M3.0 x 08 FL-TX 1 0515-1035
