Troubleshooting
Self-Test Failures and Related Troubleshooting
1-15
Self-Test Failures and Related Troubleshooting
This section has a two column table: one column has self-test errors and a second column has a list of sections
to go for assembly level troubleshooting procedures.
Table 1-12 Self-Test Failures and Related Troubleshooting
If a self-test for this
assembly fails...
Go to this assembly troubleshooting section...
A5 Sampler “Self-Tests 2xx: A5 Sampler Self-Test Errors” on page 1-24
200 Power Supply
201 Tuning + Bias Test
202 Coarse Loop Detector
203 YO Loop Detector
A7 Reference “Self-Tests 3xx: A7 Reference (Standard) Self-Test Errors” on page 1-26
300 1 GHz Detector
301 Tuning Voltage
A8 Output “Self-Tests 4xx: A8 Output Self-Test Errors” on page 1-27
400 Lowband Ground and PTAT Test
401 Prelevel Loop Test
402 Switching Filter Test
403 ALC Mod System Test
404 Mod System Test
405 Het Band Test
406 RF Path Test
A9 YIG Driver “Self-Tests 6xx: A9 YIG Driver Self-Test Errors” on page 1-29
600 Post Regulator
601 DACs
602 PLL Regulators
603 FM Driver
A6 Frac-N “Self-Tests 7xx: A6 Frac-N Self-Test Errors” on page 1-31
700 Ref Voltage
701 Loop Gain
702 Tuning Voltage
703 Output Voltage
704 Filter Test
705 F/2 Test
706 FM Path Test
