Replaceable Parts
Hardware and Other Instrument Parts
3-54
Outer and Inner Instrument Covers and Associated Parts
Figure 3-28 Outer and Inner Instrument Covers and Associated Parts
Table 3-28 Outer and Inner Instrument Covers and Associated Parts
Item No. Description Qty Part Number
1 Assy-Strap Handle - includes the following parts: 1 E8251-60067
Strap Assembly 1
Ground Spring 2
Handle Retainer 2
End Cap 2
Screw-Machine M5 x 18 FL-TX 2
2 Rear Feet Screws 4 0515-0636
3 Rear-Panel Feet 4 5041-9611
4 Feet-Bottom 4 5041-9167
5 Tilt Stand 2 1460-1345
6 Outside Instrument Cover 1 E8251-00012
