Replaceable Parts
Cables
3-32
MID Bottom View
Table 3-13 MID Bottom View
Reference
Designator
Description Qty Part Number
W36 Ribbon Cable, AT1 to J13 of A26 MID Option 1E1 1 5062-6646
W37 Semi-Rigid Cable, A23 Low Band Coupler/Detector to A31 Motherboard (Output) 1 E8251-20020
W38 Semi-Rigid Cable, A28 YIG Oscillator to J1 of A29 20 GHz Doubler 1 E8251-20014
W39 Semi-Rigid Cable, J4 of A29 20 GHz Doubler to A31 Motherboard (Sampler) 1 E8251-20015
W40 Semi-Rigid Cable, J3 of A29 20 GHz Doubler to A31 Motherboard (Frac-N) 1 E8251-20016
W41 Semi-Rigid Cable, J2 of A29 20 GHz Doubler to J1 of A30 Modulation Filter 1 E8251-20017
