Replaceable Parts
Cables
3-26
Rear Panel View
Table 3-10 Rear Panel View
Reference
Designator
Description Qty Part Number
A22W1
*
*. This cable is not replaceable by itself. You must order the corresponding assembly.
A22 Line Module to A19 Power Supply 1 (part of A22)
A22W2
* A22 Line Module to chassis ground post on rear-panel 1 (part of A22)
A32W1
* Wire Cable, A32 Crystal Oscillator to P2 of A21 Rear-Panel Interface Option UNJ 1 (part of A32)
B1W1
* Wire Cable, B1 Fan to P6 of A21 Rear-Panel Interface 1 (part of B1)
W20 Ribbon Cable, J1 of A20 SMI to J20 of A26 MID 1 8121-0677
W21 Flexible Cable, J1043 of A31 Motherboard to rear-panel (10 MHz OUT) 1 8121-0622
W22 Flexible Cable, J1042 of A31 Motherboard to rear-panel (10 MHz IN) 1 8121-0622
W23 Ribbon Cable, J2 of A21 Rear-Panel Interface to P241 of A31 Motherboard 1 8121-0611
W47 Flexible Cable, J2 of A32 Crystal Oscillator to Rear-Panel (10 MHz EFC) Option UNJ 1 8121-6839
W48 Flexible Cable, J1 of A32 Crystal Oscillator to J1041 of A31 Motherboard Option UNJ 1 8121-0621
