Replaceable Parts
Cables
3-30
MID Top View (E8241A and E8251A Models Only)
Table 3-12 MID Top View (E8241A and E8251A Models Only)
Reference
Designator
Description Qty Part Number
A25BW1
*
*. This cable is not replaceable by itself. You must order the corresponding assembly.
Wire Cable, A25B High Band Detector Bias Board to J12 of A26 MID 1 (part of A25)
W24 Semi-Rigid Cable, A24 20 GHz High Band Coupler Output to AT1 Input Option 1E1 1 E8251-20026
W25 Semi-Rigid Cable, AT1 output to APC 3.5 RF Output Adapter Option 1E1 1 E8251-20027
W26 Semi-Rigid Cable, A24 20 GHz High Band Coupler Output to APC 3.5 RF Output Adapter (models
without Option 1E1) not shown
1 E8251-20034
W27 Semi-Rigid Cable, A23 Low Band Coupler/Detector Input to J3 of A30 Modulator Filter with Standard or
High Power
1 E8251-20031
W28 Ribbon Cable, J100 of A23 Low Band Coupler/Detector to J15 of A26 MID 1 8121-0616
W48 Semi rigid Cable, A24 20 GHz High Band Coupler to J2 of A30 Modulator Filter with Standard or High
Power
1 E8251-20021
W33 Ribbon Cable, J32 of A26 MID to J10 of A29 20 GHz Doubler 1 8121-0613
W34 Ribbon Cable, J31 of A26 MID to J10 of A30 Modulator Filter with Standard or High Power 1 8121-0613
W35 Ribbon Cable, J10 of A26 MID to P201 of A31 Motherboard 1 8121-0615
W36 Ribbon Cable, AT1 to J13 of MID Option 1E1 1 5062-6646
Load Load 50 ohm, J4 of A30 Modulation Filter 1 1810-0118
