Replaceable Parts
Cables
3-28
MID Top View (E8244A and E8254A Models Only)
Table 3-11 MID Top View (E8244A and E8254A Models Only)
Reference
Designator
Description Qty Part Number
A25BW1
*
*. This cable is not replaceable by itself. You must order the corresponding assembly.
Wire Cable, A25B High Band Detector Bias board to J12 of A26 MID 1 (part of A25)
W24 Semi-Rigid Cable, A24 High Band Coupler output to AT1 input Option 1E1 1 E8251-20025
W25 Semi-Rigid Cable, AT1 output to 2.4 mm RF Output adapter Option 1E1 1 E8251-20028
W26 Semi-Rigid Cable, A24 High Band Coupler output to 2.4mm RF Output adapter (models without Option
1E1) not shown
1 E8251-20035
W27 Semi-Rigid Cable, J2 of A23 Low Band Coupler/Detector to J3 of A30 Modulator Filter with Standard or
High Power
1 E8251-20031
W28 Ribbon Cable, J100 of A23 Low Band Coupler/Detector to J15 of A26 MID 1 8121-0616
W29 Ribbon Cable, J10 of A27 40 GHz Doubler to J33 of A26 MID 1 8121-0613
W30 Semi-Rigid Cable, J2 of A27 40 GHz Doubler output to A24 High Band Coupler input 1 E8251-20024
W31 Semi-Rigid Cable, J3 of A27 40 GHz Doubler to J2 of A30 Modulator Filter with Standard or High
Power
1 E8251-20023
W32 Semi-Rigid Cable, J1 of A27 40 GHz Doubler to J4 of A30 Modulator Filter with Standard or High
Power
1 E8251-20022
W33 Ribbon Cable, J32 of A26 MID to J10 of A29 20 GHz Doubler 1 8121-0613
W34 Ribbon Cable, J31 of A26 MID to J10 of A30 Modulator Filter with Standard or High Power 1 8121-0613
W35 Ribbon Cable, J10 of A26 MID to P201 of A31 Motherboard 1 8121-0615
