Replaceable Parts
Hardware and Other Instrument Parts
3-40
Disassembled Rear Panel View
Table 3-17 Disassembled Rear Panel View
Item No. Description Qty Part Number
1 Rear Panel 1 E8251-00005
2 Screw-Machine M3.0 8 CW-PN-TX (mounting screws for rear-panel and rear struts) 10 0515-0372
3 Screw-Machine M3.0 14CW-PN-TX (screw to mount B1 fan to rear-panel) 4 0515-0665
4 Beveled Washer (fan) 4 3050-1628
5 Grommet (fan) 4 0400-0356
6 Nut-Hex 1/2-28 (4 BNC connectors on rear-panel board) 4 2950-0054
7 Washer Lock .505ID (4 BNC connectors on rear-panel) 4 2190-0068
8 Nut-Hex 15/32-32 (10 MHz In/Out BNC connectors) 2 2950-0035
9 Washer .490ID (10 MHz In/Out BNC connectors) 2 3050-1919
10 Rear-Panel RF Output Hole Plug (models without Option 1EM) 1 6960-0003
11 Standoff Screw-Hex .321I 4-40ss (Auxiliary Interface and SMI) 2 0380-2079
12 Split Lock Washer .115ID 4 (Auxiliary Interface and SMI) 2 2190-0003
13 Standoff Screw-Hex .327 6-32 (GPIB interface) 4 0380-0644
14 Split Lock Washer .194ID 10 (GPIB interface) 2 2190-0577
15 Screw-Machine M3.0 8 FL-TX (line module) 2 0515-1035
16 Right Rear Strut 1 E8251-00006
17 Left Rear Strut 1 E8251-00015
