Part Names

Number Name & description

1 Handset (IX-MV7-HW and IX-MV7-HB only)

2 LCD display (touch panel)

3 Camera

This shows a video of the other person during calls.

4 Status indicator (orange/blue)

This shows the status of this station.

(→page 11)

5 Microphone

6 Home button

Press this to display the Home screen. Pressing this while the Home screen is displayed will switch

to standby mode.

(→page 14)

7 Speaker

8 Reset button

This is for use by service personnel only. Do not press it.

9 microSD card slot

This is used to insert a microSD card (sold separately).

(→page 26)

10 microSD card slot cover

11 3.5 mm 4-pole stereo mini jack (CTIA standard)

This is used to connect a headset or the like for calls.

(→page 24)

12 Camera angle adjustment lever

This is used to adjust the angle of the camera up and down.

(→page 13)

13 Privacy mask lever

This is used to hide the camera.
