Chapter 7: Creating and Editing Programs
Page 116
Assigning Notes to the Drum Pads
The preset note numbers for the drum pads are as follows:
PAD A PAD B PAD C PAD D
Pad 1-16 = 35 - 50 Pad 1-16 = 51 - 66 Pad 1-16 = 67 - 82 Pad 1-16 = 83 - 98
You can assign different note numbers if you want to.
From the Program screen, select the Pad: field with the CURSOR keys and select a drum pad
that you want to assign a note to with the DATA wheel or by hitting one of the drum pads.
Select the Note: field on the right by pressing CURSOR RIGHT key and set the note number
with the DATA wheel.
You can change this field by playing a drum pad when the cursor is in this field. This way, you are
able to assign notes continuously without moving the cursor.
You can display a list of the notes assigned to the drum pads by selecting the Pad: or Note:
field and pressing OPEN WINDOW .
Select a drum pad with the CURSOR key or by hitting the drum pad. The note number assigned
to that selected pad is displayed at the top of the screen.
.......................................................
..................................................................................................
Pgm: 1-NewPgm-A
PLAY
ASSIGN PARAMS AUTO
Pad:A01=Note:37 Pad assign:PROGRAMPad assign:PROGRAM
Note:60=Snd:OFF
Mode:NORMAL
DRUM PURGE
.......................................................
..................................................................................................
Pgm: 1-NewPgm-A
PLAY
ASSIGN PARAMS AUTO
Pad:A01=Note:37 Pad assign:PROGRAMPad assign:PROGRAM
Note:60=Snd:OFF
Mode:NORMAL
DRUM PURGE
........................
......................................................................................................
.........................................................................................................
............................
CLOSE
Assignment View
Bank:A Note:Bank:A Note:37=OFF
-- -- -- --
-- -- -- --
-- -- -- --
-- -- -- --

Table of Contents

Other manuals for Akai MPC 2000XL

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Akai MPC 2000XL and is the answer not in the manual?

Akai MPC 2000XL Specifications

General IconGeneral
Polyphony32 voices
Sampling Frequency44.1 kHz
Sampling Resolution16-bit
Sample Memory2MB standard, expandable to 32MB
Pads16 velocity-sensitive pads
Sequencer Resolution96 PPQN
Outputs8 individual outputs, stereo master output
FilterDigital resonant filter
Display240 x 64 pixel LCD
TypeSampler/Sequencer
Storage3.5" floppy disk
EffectsOptional effects board
Power SupplyAC 100-240V, 50/60 Hz
Maximum Sampling Time22.8 minutes (with 32 MB RAM)
