Sending Effects
Effect send can only be used when the optional EB16 effect board is installed.
Press FXsend (F3) to display the effect send screen.
Assigning the Effect to be Used
Move the cursor to the top of the screen with the CURSOR UP key and select the channel that you
want to assign an effect to (use the CURSOR LEFT/RIGHT keys or drum pads).
Turn the DATA wheel to select the effect that you want to use:
M1 / M2 = Multi effects 1 or 2
R1 / R2 = Reverb 1 or 2
Setting the Effect Send Level
Move the cursor to the lower part of the screen with the CURSOR DOWN key and select the
channel whose effect send level you want to adjust (use the CURSOR LEFT/RIGHT keys or drum
pads).
Turn the DATA wheel to adjust the level.
Adjusting all the Channel’s Effect Send Levels/Effect Assign at the Same Time
By pressing the ALL CH [F6] key while in the effect send level or effect assign field, all the
channels are linked together and can all be adjusted at the same time.
Press CLEAR [F6] to cancel the link mode.
