Akai MPC 2000XL User Manual

Chapter 11: Flash ROM
Page 173
Flash ROM
By installing the optional flash ROM board FMX008M (which has 8MB of memory), you can save
data to the flash ROM. Saving data to the flash ROM saves RAM space.
When you are installing the flash ROM board, please refer to the manual supplied with it.
Formatting the Flash ROM
Before using the flash ROM, you must format it first. Enter Disk mode by holding down
SHIFT and pressing LOAD (3 on the numeric pad). Select F-ROM in the Device: field
and press FORMAT [F3] to display the format screen.
SAVE SETUPLOAD FORMAT DO IT
Device:F-ROM
 THIS WILL ERASE THE ENTIRE DISK!!THIS WILL ERASE THE ENTIRE DISK!!
.......................................................................................................................
Press DO IT [F6].
........................................................................................
............................
........................
CLOSE DO IT
THIS WILL ERASETHIS WILL ERASE
 THE ENTIRE F-ROM!!THE ENTIRE F-ROM!!
....................................................................................
Format F-ROMFormat F-ROM
The above message appears, and the format begins when you press DO IT [F5].
Note: Once formatting is carried out, all of the data on the flash ROM will be
erased.

Akai MPC 2000XL Specifications

General

Polyphony	32 voices
Sampling Frequency	44.1 kHz
Sampling Resolution	16-bit
Sample Memory	2MB standard, expandable to 32MB
Pads	16 velocity-sensitive pads
Sequencer Resolution	96 PPQN
Outputs	8 individual outputs, stereo master output
Filter	Digital resonant filter
Display	240 x 64 pixel LCD
Type	Sampler/Sequencer
Storage	3.5" floppy disk
Effects	Optional effects board
Power Supply	AC 100-240V, 50/60 Hz
Maximum Sampling Time	22.8 minutes (with 32 MB RAM)
