Akai MPC 2000XL User Manual

Chapter 7: Creating and Editing Programs
Page 120
DCY SW
This switches between the sound assigned to the program and the two sounds set here using the
value set in the Decay field (see following pages). When this option is selected, two If
over: fields appear to the right of the Mode: field. Set the decay value and note here. In the
following example, the sound assigned to the selected note number generates MIDI note number
60 up to decay 44, 36/A02 between decay values 45 to 88, and 53/A16 for velocity over 89.
.......................................................
..................................................................................................
Pgm: 1-NewPgm-A
PLAY
ASSIGN PARAMS AUTO
Pad:A01=Note:37 Pad assign:PROGRAMPad assign:PROGRAM
Note:60=Snd:TAM

If over: 44, use:36/A02If over: 44, use:36/A02
Mode:DCY SWDCY SW If over: 88, use:53/A16If over: 88, use:53/A16
DRUM PURGE
Normally the DECAY is assigned to the NOTE VARIATION slider and is used to switch the sound
by changing the decay parameter with the NOTE VARIATION slider. For example, by using this
as a hi-hat sound, you can switch between closed, half, and open sounds effectively.

Akai MPC 2000XL Specifications

General

Polyphony	32 voices
Sampling Frequency	44.1 kHz
Sampling Resolution	16-bit
Sample Memory	2MB standard, expandable to 32MB
Pads	16 velocity-sensitive pads
Sequencer Resolution	96 PPQN
Outputs	8 individual outputs, stereo master output
Filter	Digital resonant filter
Display	240 x 64 pixel LCD
Type	Sampler/Sequencer
Storage	3.5" floppy disk
Effects	Optional effects board
Power Supply	AC 100-240V, 50/60 Hz
Maximum Sampling Time	22.8 minutes (with 32 MB RAM)
