User Guide
62
the PSE stabilizes the voltage to around 48 V DC and the normal powering operation
starts.
Table 3.5: Cable test results
Result Description
Status Displays the current PoE / PoE+ measurement status. The
Status could be any of the following items:
• Measuring: The system has detected PoE or PoE+ and it
is measuring normally.
• No PoE: No PoE / PoE+ detected. No test result is dis-
played.
• Error: Unspecified error condition. It should never appear
in normal circumstances.
Voltage Displays the voltage measured between wires 1/2 and 3/6
(Alternative A). This result is available both in endpoint and
pass-through modes.
Polarity alternative A If the current powering alternative is Alternative A, it displays
which of the 1/2 or 7/8 wires has positive and negative
polarity. If the power alternative is Alternative B, it displays no
result.
Current If the powering alternative is Alternative A, it displays the
current injected in the PD.If the power alternative is
Alternative B, it displays no result.
This result is available only in the equipment is connected
between the PD and PSE in pass-through mode.
Power If the powering alternative is Alternative A, it displays the
power injected in the PD. If the power alternative is Alternative
B, it displays no result.
This result is available only in the equipment is connected
between the PD and PSE in pass-through mode.
Polarity alternative B Displays the voltage measured between wires 4/5 and 7/8
(Alternative B). This result is available both in endpoint and
pass-through modes.
Current Displays the Alternative B current in the same conditions that
the Alternative A
Power Displays the Alternative B power in the same conditions that
the Alternative A current
