Traffic Generation
75
8. If necessary, repeat the bandwidth profile configuration process for one or more
traffic flows (Flow #1 to Flow #8) available from the Bandwidth profile menu.
Figure 4.4: Bandwidth profiles for Albedo xGenius: (a) Continuous traffic generation, (b)
Periodic burst generation, (c) Ramp generation, (d) Random traffic generation with
Poisson probability distribution.
Traffic (Mb/s, frames/s,%)
Time (s)
Traffic (Mb/s, frames/s,%)
Time (s)
Traffic (Mb/s, frames/s,%)
Time (s)
Traffic (Mb/s, frames/s,%)
Time (s)
Rate (average)
Rate (final)
Rate (final)
Rate (high)
Rate (low)
Rate
(a)
(b)
(c)
(d)
Step duration
Duration (low)
Duration (high)
