Mandatory Regulations
7705 SAR-8 Installation Guide Page 31
Regulatory Symbols
The 7705 SAR-8 uses various regulatory approvals symbols. They may be used on product
markings such as approvals labels. These symbols are described in IEC 417.
Figure 1 and Figure 2 show symbols of a terminal that you must connect to earth ground
before you make any other connections to the equipment.
Figure 1: Protective Earth (ground)
Figure 2: Earth (ground)
