7705 SAR-8 Overview

7705 SAR-8 Installation Guide Page 61

SAR System Installation Process

To install the 7705 SAR-8 system, perform the installation procedures in the following

order:

Step 1. Prepare the site.

Step 2. Unpack the chassis.

Step 3. Mount and ground the chassis.

Step 4. Prepare and connect the DC input power cables.

Step 5. Install the components.

Step 6. Power up the system.

Step 7. Connect the network cables.

Step 8. Provision (preconfigure) the system.
