OmniAccess 780 Hardware Users Guide
Alcatel-Lucent
SE/L2GE CONNECTOR PIN ASSIGNMENTS
The following table details the SE/L2GE connector pin details for the
OA-780:
Table 4: 10/100/1000 Mbps Port Connector Pin Assignment on SE/L2GE
Card
Pin #
In 10 Base-T and 100 Base-Tx
Mode
In 1000 Base-Tx Mode
1TX + TD0 +
2TX - TD0 -
3RX + TD1 +
4 NC (No Connection) TD2 +
5NC TD2 -
6RX - TD1 -
7NC TD3 +
8NC TD3 -
