Alcatel-Lucent OmniAccess 780 User Manual

Hardware Overview
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
21
Alcatel-Lucent
Beta Beta
OmniAccess 780 Hardware Users Guide
Table 10: T1E1 Mode LEDs
L2 8-
PORT GIGABIT ETHERNET LINE CARD
The 8-port GigE line card provides Layer-2 switching functions. The line card can
be installed in any of the line card slots of the chassis. (i.e., 0, 1, 2, 3, 4, or 5). The
GigE card has 8 RJ-45 interfaces. These interfaces can auto-negotiate, transmit,
and receive data packets at rates of 10/100/1000 Mbps.
1. GigE Card LEDs
2. RJ-45 Interfaces
3. Thumb Screw
Figure 9: GigE Line Card
T1 E1B E1U Description
On Off Off Line card configured in T1 mode.
Off On Off Line Card Configured in E1 balance mode.
Off Off On Line Card Configured in E1 unbalance mode.
Off Off Off No mode configured on line card.
OA7-GE-8
2
GigE Port LED 0
LED1
LED2
3
LED4LED3 LED5 LED6
LED7
1
