Hardware Overview
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
26
Alcatel-Lucent
Beta Beta
OmniAccess 780 Hardware Users Guide
USP Card (V.35/X.21/RS-232) Cable Details
The following table lists the part numbers for the Alcatel specific V.35/X.21/RS-
232 cables:
Table 15: USP Card (V.35/X.21/RS-232) Cable Part Numbers
Note: Refer to “Pin Connector Details for OmniAccess 780” for detailed information on or
USP line card pin connector details, and V.35/X.21/RS-232 DTE and DCE cable pin
out details.
Part No. Description
120300-00 Cable ASSY V.35 DCE Cable with Female Connector (68 Pin
SCSI Connector to V.35 DCE Female Connector)
120301-00 Cable ASSY V.35 DTE Cable with Male Connector (68 Pin
SCSI Connector to V.35 DTE Male Connector)
120302-00 Cable ASSY X.21 DCE Cable with Female Connector (68 Pin
SCSI Connector to X.21 DB15 Female Connector)
120303-00 Cable ASSY X.21 DTE Cable with Male Connector (68 Pin
SCSI Connector to X.21 DB15 Male Connector)
120298-00 Cable ASSY RS-232 DCE Cable with Female Connector (68
Pin SCSI Connector to RS-232 DB25 Female Connector)
120299-00 Cable ASSY RS-232 DTE Cable with Male Connector (68 Pin
SCSI Connector to RS-232 DB25 Male Connector)
