CONNECTING THROUGH EXTERNAL NETWORK
To establish a link between the OA-780 and the external network (WAN/Internet),
connect the RJ-11 jack from the external modem to the modem port provided in
the fan tray on the front panel of the OA-780.
Figure 23: Connecting through External Network
RJ-11 Modem Port
RJ-11 Connector
Port 0
Port 1
