CABLE CONNECTION TABLE
The following table summarizes the cable connections for the OA-780.
Table 4: Cable Connections Table
Port or Module Port Type Connect To
Power Tray IEC 60320 (320) C-14 Power Inlet Main power supply
Ethernet RJ-45 Ethernet hub or switch
T 1 E 1 R J - 4 5 T 1 E 1 n e t w o r k
Console RJ-45 PC or VT100
Modem RJ-11 Telephone Line
Serial 68 pin VHDCI Connector V.35/X.21/RS-232 modem
