SE Card LEDs
SE card has status LEDs for the card and for each of its Ethernet ports.
Table 6: SE Card LEDs
Table 7: LEDs for Ethernet Port on SE Card
LED Status Description
Active Green SE card is active
Fault Red Reload in progress
LED Status Description
Left LED Green Link Speed is 1000/10 Mbps
Yellow Link Speed is 100 Mbps
Off Link is not active
Right LED Amber Traffic is active
Off Traffic is not active
