Pin Connector Details for OmniAccess 780
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
27
Alcatel-Lucent
Beta Beta
OmniAccess 780 Hardware Users Guide
B11 PORT2_TxD_B B45 PORT2_TxD_A
B12 P2P3_CMODE2 B46 P2P3_CMODE3
B13 PORT2_RxTiming_B B47 PORT2_RxTiming_A
B14 P2P3_CMODE4 B48 Signal Ground
B15 PORT2_TxTiming_B B49 PORT2_TxTiming_A
B16 Signal Ground B50 Signal Ground
B17 PORT2_TXC_B B51 PORT2_TXC_A
B18 CHASSIS_GND B52 Signal Ground
B19 PORT3_RTS_B B53 PORT3_RTS_A
B20 PORT3_CTS_B B54 PORT3_CTS_A
B21 PORT3_DSR_B B55 PORT3_DSR_A
B22 PORT3_DCD_B B56 PORT3_DCD_A
B23 PORT3_DTR_B B57 PORT3_DTR_A
B24 PORT3_RI B58 PORT3_RL
B25 PORT3_TM B59 PORT3_LL
B26 PORT3_RxD_B B60 PORT3_RxD_A
B27 No Connect B61 No Connect
B28 PORT3_TxD_B B62 PORT3_TxD_A
B29 No Connect B63 No Connect
B30 PORT3_RxTiming_B B64 PORT3_RxTiming_A
B31 No Connect B65 Signal Ground
B32 PORT3_TxTiming_B B66 PORT3_TxTiming_A
B33 Signal Ground B67 Signal Ground
B34 PORT3_TXC_B B68 PORT3_TXC_A
Pin# Signal Name Pin# Signal Name
