LED 5 Off Port 5 link is not active.
Solid Green Port 5 link is active.
Blinking Green Port 5 link and traffic is active.
LED 6 Off Port 6 link is not active.
Solid Green Port 6 link is active.
Blinking Green Port 6 link and traffic is active.
LED 7 Off Port 7 link is not active.
Solid Green Port 7 link is active.
Blinking Green Port 7 link and traffic is active.
LED Status Description
