ALL-TEST PRO 7 - Front Panel Layout; Rear View

ALL-TEST PRO 7™ User Manual
©2019 ALL-TEST Pro, LLC All Rights Reserved 10 Rev 06/20/2019
Front Panel Layout
Rear View
⓫
⓬
ALL-TEST PRO 7 series manufacturers
nameplate and identity tag
Lithium Ion Battery Pack
❼
❽
❾
❿
Charging status indicator, bicolor LED,
Red: charging in progress
Green: Fully charged
Graphical LCD display 128x128, white
LED backlight
Status indicator LED
15 Key Input pad area, backlit sealed
tactile switches
