Publication 0160-5.18 - June 2003
DeviceNet Information B-23
Class Code 0x04 —
Assembly Objects
Instance 1 to 105 Attributes: I/O Instances
Instance 191 to 193 Attributes: Configuration Instances
Common Services
Class Attributes: None Supported Number of Instances: 19
Attribute ID
Access
Rule
Name Data Type Min/Max Default Description
3 Get Data See instance data format for individual I/O assemblies on pages B-24 through B-28.
Attribute ID
Access
Rule
Name Data Type Min/Max Default Description
3 Get/Set Data See configuration assembly data formats for individual configuration assemblies on pages B-29 and B-30.
Service
Code
Implemented for:
Service
Name
Class Instance
0x0E No Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
