Publication 0160-5.18 - June 2003
Chapter 3
Installation and Wiring
This chapter contains information necessary to:
• Meet requirements for CE compliance (EMC / Low Voltage directives).
• Suppress transient EMI from “hard contact” load switching.
• Reduce high frequency common mode noise current.
• Properly connect/disconnect power to the motor.
• Remove a preinstalled Program Keypad Module or Ready/Fault
Indicating Panel.
• Configure and install the Communication Module.
• Wire the DeviceNet communication cables.
• Remove an installed Communication Module from the drive.
Read this chapter completely before you attempt to install or
configure the Communication Module. Before you apply power,
review the Safety Precautions
on Preface page P-3, making sure that
all connections are secure and all selections are correct.
Required Tools and Equipment Before installing and configuring the 160-DN2 Communication
Module, make sure that the contents of the shipping box include:
• Bulletin 160-DN2 module (Catalog Number 160-DN2)
• 10 pin linear Plug (Part Number 1787-PLUG10R)
• this manual
In addition, you will need to supply:
• a small blade screwdriver
• DeviceNet configuration software or hardware device
• DeviceNet thick cable or thin cable. For details and part numbers,
refer to the DeviceNet Product Overview, Publication DN-2.5.
!
ATTENTION: When you make changes to the
switch settings, use a blunt pointed instrument. Do not
use a pencil or pen because damage may occur.
!
ATTENTION: Unpredictable operation may occur if
you fail to check connections and DIP switch settings
for compatibility with your application. Unpredictable
operation may result in personal injury, death, and
equipment damage.
