Publication 0160-5.18 - June 2003
Appendix A
Specifications
Electrical
Environmental
Communications
Mechanical
➀ Use this value to size the network current draw from the power supply.
➁ When installed on the 160 SSC drive, the communication module adds
approximately 21.4 mm (0.85 in.) to the overall depth.
Network Supply Voltage 11 to 25V dc
Node Current Consumption 40 mA maximum
➀
Power Consumption 1W maximum
Ambient Temperature
Operating
Storage
0 to 50° C (32 to 122° F)
-40 to 85° C (-40 to 185° F)
Relative Humidity 0 to 95% non-condensing
Vibration
1.0 G operational
2.5 G non-operational
Shock
15.0 G operational
30.0 G non-operational
Altitude 1,000 m (3,300 ft.) without derating
DeviceNet
Baud Rates
Distance maximum
125, 250 or 500 kbps
500 m (1640 ft.) @ 125 kbps
200 m (820 ft.) @ 250 kbps
100 m (328 ft.) @ 500 kbps
Dimensions
Height
Width
Depth
➁
67.5 mm (2.68 in.)
70.0 mm (2.76 in.)
45.4 mm (1.79 in.)
