Allen-Bradley 160-DN2 - Class Code 0 X05 - Connection Object

Publication 0160-5.18 - June 2003
B-6 DeviceNet Information
Class Code 0x05 —
Connection Object
Instance 1 Attributes: Explicit Message Instance
Class Attributes: None Supported Number of Instances: 3
Attribute ID Access Rule Name Data Type Value
1 Get State USINT
0 = Nonexistant
1 = Configuring
3 = Established
4 = Timed out
5 = Deferred delete
2 Get Instance Type USINT 0 = Explicit Message
3 Get Transport Class Trigger USINT 0x83
4 Get Produced Connection ID UINT
10xxxxxx100
where xxxxxx = Node address
5 Get Consumed Connection ID UINT
10xxxxxx100
where xxxxxx = Node address
6 Get Initial Comm. Characteristics USINT 0x22
7 Get Produced Connection Size UINT 7
8 Get Consumed Connection Size UINT 7
9 Get/Set Expected Packet Rate UINT Timer resolution of 10 msec.
12 Get/Set Watchdog Action USINT
1 = Auto delete
3 = Deferred delete
13 Get Produced Connection Path Length UINT 0
14 Get Produced Connection Path Null (no data)
15 Get Consumed Connection Path Length UINT 0
16 Get Consumed Connection Path Null (no data)
