Allen-Bradley 160-DN2 - Class Code 0 X10 - Parameter Group Object

Publication 0160-5.18 - June 2003
DeviceNet Information B-11
Class Code 0x10 —
Parameter Group Object
Class Attributes
Number of Instances: 3
Instance 1 through 3 Attributes
➀ Value varies based on parameter group instance.
Common Services
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
2 Get Max Instance UINT 3
8 Get Native Language USINT 0 = English
Attribute ID Access Rule Name Data Type Value
1 Get Group Name String SHORT_STRING
➀
2 Get Number of members in group UINT
➀
3 Get 1st Parameter Number in Group UINT
➀
4 Get 2nd Parameter Number in Group UINT
➀
n Get (n-2)th Parameter Number in Group UINT
➀
Service
Code
Implemented for:
Service
Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
0x01 Yes Yes Get_Attributes_All
