Publication 0160-5.18 - June 2003
DeviceNet Information B-3
Class Code 0x01 —
Identity Object
Class Attributes
Number of Instances: 2
Instance 1 Attributes: Drive Instance
➀ For example, firmware revision 5.01 has a major revision of “5” and a minor revision of “1.”
Attribute ID Access Rule Name Data Type Value
1 Get Revision UINT 1
2 Get Max Instances UINT 2
6 Get Max ID Class UINT 7
7 Get Max ID Instance UINT 7
Attribute ID Access Rule Name Data Type Value
1 Get Vendor UINT 1
2 Get Product Type UINT 2
3 Get Product Code UINT —
4 Get
Revision
Major Revision
Minor Revision
Structure of:
USINT
USINT
xxxxxxxxxx
X
➀
X ➀
5 Get Status WORD
0 = Not owned
1 = Owned by master
6 Get Serial Number UDINT unique number
7 Get
Product Name
String Length
ASCII String
Structure of:
USINT
STRING
32
“Bulletin 160 Preset 0.37kW 230V”
9 Get Configuration Consistency UINT Checksum
