Allen-Bradley 160-DN2 User Manual

Publication 0160-5.18 - June 2003
B-4 DeviceNet Information
Class Code 0x01—
Identity Object (Continued)
Instance 2 Attributes: DeviceNet Instance
Common Services
Attribute ID Access ID Name Data Type Value
1 Get Vendor UINT 1
2 Get Product Type UINT 105 = Subassembly
3 Get Product Code UINT 1
4Get
Revision
Major
Minor
Structure of
USINT
USINT
3
1
5 Get Status WORD
0 = Not Owned
1 = Owned by Master
6 Get Serial Number UDINT Unique 32 bit number
7Get
Product Name
String Length
ASCII String
Structure of
USINT
STRING
16
“Bulletin 160 DN2”
Service
Code
Implemented for:
Service
Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
0x05 No Yes Reset
